0-0.8Mpa Female Thread 1/4" RO Solenoid Valve for Water Purifier
This RO water solenoid valve is normally close. The body material can be PP or POM and it with a white, plastic bottom. The valve voltage can be AC and DC, it's easy to use and our service is very well. We will reply you at once when you ask us what you want to know, waiting for your cooperation.
Information of RO Electromagnetic valve:
| Part name | RO water valve |
| Application | Reverse Osmosis system |
| Principium | Directly acting type |
| Pattern | Two-port two-position |
| Control mode | Normally close |
| Medium | Water, Air, Oil ect |
| Medium temperature | 0~100°C |
| Working pressure | 0~120psi |
| Connecting port size | Female Thread 1/4" |
| Orifice | 2.5mm |
| Valve voltage | DC12V 24V 36V 48V |
| Body material | PP, POM all available |
| Seal | NBR, EPDM, VITON |
| Packaging | Inner box, carton, then packed by pallet |
| Delivery time | According to your order quantity, normally 2 weeks |
The Working Principle of Normal Close Solenoid Valve:
When the coil is energized, the electromagnet force is generated, so that the moving iron core overcomes the spring force and attracts the direct opening of the valve with the static core. The medium shows the passage; when the coil is de-energized, the electromagnetic force disappears, Core in the spring force under the action of reset, directly close the valve port, the media barrier. Simple structure, reliable, zero pressure and micro-vacuum under normal work.
Advantage of Our Solenoid Valve:
1. Using high quality material, long product life
2. AC voltage type no noise
3, Many kinds of welding procedure optional to make sure the strength
4, After each part machining, we wash them to achieve nice apperance
5, After assembling, we test leakage and noise and function 100% pieces
About Service:
1. We offer professional order operation service: Same sales person follows the order from discussing step to the end of you get the goods of order
2. If any problem occur during production or you meet quality problem when you are using our goods, inform us at once, we will offer you best solution
3. Contact us via email, phone calling, skype, or other chatting methods, we will response at once
The pictures about the solenoid valve:
Welcome your any question, we will response at once. We also can produce as customized.
Welcome your drawing or sample.
