1/4'' NPT 5/2 Way 4V320-08 Double Solenoid Pneumatic Control Valve 12V 24V 110V 220V
4V series AirTAC type pneumatic solenoid valve for air, two or three positions, five-way-5/2 (3) -way, double solenoid valve, can be used for voltage DC 12V, DC 24V, AC 110V and AC 220 Volt, Pilot Valve-Operating Mode, Port Size M5 × 0.8, Rc 1/8 ", 1/4", 3/8 "for your choice, fast and safe opening / closing. High reliability and low price. 4V Series AirTAC type solenoid valve is used as a directional control component to change the direction of the working medium to drive the actuator assembly, usually through a cylinder to achieve cyclic movement.
4V Series Solenoid Valve Features:
1. Pilot-oriented mode: optional for internal or external;
2. Structure in sliding column mode: good tightness and sensitive reaction;
3. Internal hole adopts special processing technology which has little attrition friction, low start pressure and long service life;
4. It is available to form integrated valve group with the base to save installation space;
5. Affiliated manual devices are equipped to facilitate installation and debugging;
6. Several standard voltage grades are optional;
Dimension of 4V320-08 Pneumatic Solenoid Valve:
Specifications of 4V Series Internal Pilot Operated Pneumatic Valve:
| Model | | 4V330C-08 4V330E-08 4V330P-08 | | 4V330C-10 4V330E-10 4V330P-10 |
| Fluid | Air(to be filtered by 40 μ m filter element) |
| Acting | Internal pilot or external pilot |
| Port Size | | In=Out=3/8'' Exhaust=1/4'' |
| Orifice Size | | | | |
| Valve Type | | | | |
| Operating Pressure | |
| Proof Pressure | |
| Temperature ℃ | |
| Material of Body | |
| Max. frequency | | | | |
Details:
Installation Instructions:
1. Before installing, be sure the valve hasn’t been damaged via transportation.
2. It’s suggested to use the medium lubricated by 40μm filter element. Be aware of the flow direction and port size.
3. Please notice whether the installation condition accords with technical requirements (such as “voltage”, “actuation frequency”, “working pressure” and “scope of application temperature”), then the equipment can be installed and used.
4. Notice the flow direction of air during installation, P is the air intake, A (B) is the work port and R (S) is the exhaust outlet.
5. Take measure to avoid vibration and frozen.
6. Before using the fittings and tubes make sure they are clean. When connecting to fittings, be sure the PTFE Thread Seal Tape is used correctly.
7. To keep the dust away, please use the silencer for the exhaust ports. Never forget to install dirt-proof boot in air intake and outlet during dismounting.
8. After installing, please use the manual override to test valve first.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
