Dual Guide Rod Air Cylinders Pneumatic SMC Type CXSWM6-30

Name: Dual Guide Rod Air Cylinders Pneumatic SMC Type CXSWM630
Brand: BRANDO
Price: 1 USD

Brand Name : BRANDO

Model Number : CXSWM, CXSWL

Certification : CE, ISO

Place of Origin : Ningbo, China

MOQ : 1 pc

Price : Negotiation

Payment Terms : L/C, T/T, PayPal, Western Union, MoneyGram

Supply Ability : 100000 pcs per month

Delivery Time : 4-7 work days

Packaging Details : Inner Box, Carton, Pallet

Cylinder Type : Dual Rod Cylinder

Bore Size (mm) : 6, 10, 16, 20, 25, 32

Standard Stroke (mm) : 10, 20, 30, 40, 50, 75, 100, 125, 150, 175, 200

Max Operating Pressure : 0.7 Mpa

Cushion : Rubber Bumper on both ends

Port Size : M5x0.8, 1/8''

Bearing Type : Slide Bearing, Ball Bushing Bearing

Piston Speed : 50 to 500mm/s

Contact Now

Dual Guide Rod Air Cylinders Pneumatic SMC Type CXSWM6-30

SMC Type CXSW Series Pneumatic Cylinder is a dual piston double rod cylinder with non-rotating accuracy ± 0.1°. The CXSWL high precision ball bushing type allows for smooth operation that ensures stable travel resistance. The CXSWM slide bearing type provides lateral stability protecting it from side load impacts. Series CXSW is available in six bore sizes (6mm, 10mm, 15mm, 20mm, 25mm, 32mm) and stroke lengths up to 200mm. This series is very compact and has a very accurate non-rotating specification. It is suited for accurate pick-and-place applications or light duty material handling. The CXSW can be used with either reed or solid state switches.

Specifications of CXSW Series Pneumatic Cylinder:

Dual Guide Rod Air Cylinders Pneumatic SMC Type CXSWM6-30

Stroke of CXSW Series Pneumatic Cylinder:

Dual Guide Rod Air Cylinders Pneumatic SMC Type CXSWM6-30

Ordering Code of CXSW Series Pneumatic Cylinder:
Dual Guide Rod Air Cylinders Pneumatic SMC Type CXSWM6-30

Theoretical Output of CXSW Series Pneumatic Cylinder:

Dual Guide Rod Air Cylinders Pneumatic SMC Type CXSWM6-30

Brando Supply Pneumatic Air Cylinders:

Airtac Type Pneumatic Cylinder	Festo Type Pneumatic Cylinder	SMC Type Pneumatic Cylinder

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
