4M310-08 Airtac Type 5 Way 2 Position Namur Solenoid Valve
5 way 2 position solenoid valve with namur interface making it suitable for direct mounting onto pneumatic actuators (both double acting and spring return). Standard features include manual override, led indicator plug (IP65), fully encapsulated low wattage coil (AC 5.5 VA, DC 4.8 Watts). Available in all voltages. Comes wtih mounting screws. Threads conform to ISO 7.1 Sealing Threads.
Technical Data of 4M Series Namur Solenoid Valve:
| Model No | 4M110-M5 4M120-M5 | 4M110-06 4M120-06 | 4M210-06 4M220-06 | 4M210-08 4M220-08 | 4M310-08 4M320-08 | 4M310-10 4M320-10 |
| Fluid | Air (to be filtered by 40 μm filter element) |
| Port Size | In=Out=M5 | In=Out=1/8'' | In=Out=1/8'' | In=1/4'', Out=1/8'' | In=Out=1/4'' | In=3/8'', Out=1/4'' |
| Orifice Size | 5.5mm² (Cv=0.31) | 12.0mm² (Cv=0.67) | 14.0mm² (Cv=0.78) | 16.0mm² (Cv=0.89) | 25.0mm² (Cv=1.40) | 30.0mm² (Cv=1.67) |
| Valve Type | 5 Way 2 Position |
| Operating Pressure | 0.15 to 0.8MPa (21 to 114 PSI) |
| Proof Pressure | 1.5MPa (215PSI) |
| Temperature (℃) | -20 to +70 |
| Body Material | Aluminum Alloy |
| Max. Frequency | 5 Cycle / Second | 4 Cycle / Second |
| Coil Voltages | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| Coil Protection Class | IP65 |
| Activating Time | 0.05 second and below |
Dimension of 4A310-08 Namur Solenoid Valve:
