3V310-10-NO Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position

Brand Name : Brando

Model Number : 3V310-10

Certification : CE

Place of Origin : China

MOQ : 1 pc

Price : Negotiation

Payment Terms : T/T, PayPal, Western Union

Supply Ability : 200000 pcs per month

Delivery Time : Negotiation

Packaging Details : Individual box, Carton, Pallet

Fluids : Air (to be filtered by 40 μ m filter element)

Acting : Internal Pilot or External Pilot

Valve Type : 3 Way 2 Position

Port Size : 3/8''

Pressure Range : 0.15 to 0.8MPa

Max Pressure Resistance : 1.5MPa

Body Material : Aluminum Alloy

Voltage : 12VDC, 24VDC, 110VAC, 220VAC

Contact Now

3V310-10-NO Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position

The 3V310-10 is a pneumatic directional solenoid valve with a three-way operation & three ports (P = Pressure, A = Outlet, EA = Exhaust for port A). Three-way, two-position valves are generally used to fully extend a single acting (spring return) cylinder, or in applications with similar operation.

Technical Data of 3V300 Series Pneumatic Solenoid Valves:

Model No

3V310-08

3V320-08

3V310-10

3V320-10
Fluid Air (to be filtered by 40 μm filter element)
Port Size In=Out=1/4'' In=Out=3/8''
Orifice Size

25.0mm²

(Cv=1.39)

30.0mm²

(Cv=1.67)
Valve Type 3 Way 2 Position
Operating Pressure 0.15 to 0.8MPa (21 to 114 PSI)
Proof Pressure 1.5MPa (215PSI)
Temperature (℃) -20 to +70
Body Material Aluminum Alloy
Coil Voltages 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Coil Protection Class IP65
Activating Time 0.05 second and below


Dimension of 3V310-10 Pneumatic Solenoid Valve:
3V310-10-NO Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position

Production Video of Pneumatic Solenoid Valves:


More Pneumatic Products for you to choose:

3V310-10-NO Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position3V310-10-NO Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position3V310-10-NO Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position
2/2 Way 3/2 Way 5/2 Way, Single Solenoid
3V310-10-NO Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position3V310-10-NO Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position3V310-10-NO Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position
5/2 Way, Double Solenoid 5/3 Way, Double Solenoid Pneumatic Hose Fittings
