Explosion Proof Hot Water Steam Brass Solenoid Valve 24V 110V 220V

Brand Name : Brando

Model Number : US-Z

Certification : CE

Place of Origin : China

MOQ : 1 pc

Price : Negotiation

Payment Terms : L/C, T/T, PayPal, Western Union, MoneyGram

Supply Ability : 100000 pcs per month

Delivery Time : 4-8 days

Packaging Details : Inner boxes, Carton, Pallet

Working Medium : Hot Water, Steam

Port Size : 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''

Orifice Size : 17mm, 22mm, 30mm, 50mm

Operation Mode : 2 Way Normally Closed

Operation : Direct Acting, Piston Pilot Operated

Body Material : Brass, Stainless Steel

Seal Material : PTFE, FKM

Pressure Range : Direct Acting: 0 to 0.8 MPa, Piston Pilot Operated: 0.1 to 1.5 MPa

Coil Voltages : 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Coil Protection Class : Explosion Proof

Contact Now

Explosion Proof Hot Water Steam Brass Solenoid Valve 24V 110V 220V

Product Features of Steam Solenoid Valves:

1. Working Medium: Hot Water, Steam, etc
2. Working Pressure Range: Direct Acting: 0 to 0.8 MPa, Piston Pilot Operated: 0.1 to 1.5 MPa
3. Seal Material: PTFE, FKM
4. Body Material: Brass, Stainless Steel
5. Port Size: 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''
6. Orifice Size: 17mm, 22mm, 30mm, 50mm
7. Operation: Direct Acting, Piston Pilot Operated
8. Coil Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Ordering Code of Steam Solenoid Valves:

Explosion Proof Hot Water Steam Brass Solenoid Valve 24V 110V 220V

Technical Data of Steam Solenoid Valves:​

2L Series
2L-10
2L-15
2L-20
2L-25
2L-35
2L-40
2L-50
US Series
US-10
US-15
US-20
US-25
US-35
US-40
US-50
Orifice Size
17
17
17
22
30
30
50
Port Size
3/8''
1/2''
3/4''
1''
1-1/4''
1-1/2''
2''
Medium
Hot Water, Steam
Action
Direct Acting, Piston Pilot Operated
Function
2 Way, Normally Closed
Body Material
Brass, Stainless Steel
Seal Material
PTFE, FKM
Pressure
Range
Direct Acting: 0 to 0.8 MPa, Piston Pilot Operated: 0.1 to 1.5 MPa
Temp. Range
PTFE: -20 to +185℃, FKM: -10 to +150℃
Coil Voltages
12VDC, 24VDC, 24VAC, 110VAC, 220VAC


Dimension of Steam Solenoid Valves:

Explosion Proof Hot Water Steam Brass Solenoid Valve 24V 110V 220V

US Series
2L Series
A
B
C
Port Size
US-10
2L-10
82
42
146
3/8''
US-15
2L-15
1/2''
US-20
2L-20
3/4''
US-25
2L-25
90
54
162
1''
US-35
2L-35
110
75
185
1 1/4''
US-40
2L-40
1 1/2''
US-50
2L-50
120
77
195
2''
