1/2'' Explosion Proof Brass Solenoid Valve High Pressure 5 MPa 24V 220V

Brand Name : Brando

Model Number : 5404-Z

Certification : CE

Place of Origin : China

MOQ : 1 pc

Price : $3 to $50 per pc

Payment Terms : L/C, T/T, PayPal, Western Union, MoneyGram

Supply Ability : 100000 pcs per month

Delivery Time : 4-8 days

Packaging Details : Inner boxes, Carton, Pallet

Working Medium : Air, Water, Oil, Steam

Port Size : 1/4'', 3/8'', 1/2''

Orifice Size : 13mm

Operation Mode : 2 Way Normally Closed

Operation : Piston Pilot Operated

Body Material : Brass

Seal Material : PTFE Seat Seal + FKM

Pressure Range : 0.3 to 5 MPa

Fluid Temperature : 0 to +180 °C

Coil Voltages : 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Coil Protection Class : Explosion Proof

Contact Now

1/2'' Explosion Proof Brass Solenoid Valve High Pressure 5 MPa 24V 220V

Product Features of 5404 Solenoid Valve:

1. Working Medium: Air, Water, Oil, Steam, etc
2. Working Pressure Range: 0.3 to 5 MPa
3. Seal Material: PTFE + FKM
4. Body Material: Brass
5. Port Size: 1/4'', 3/8'', 1/2'', 3/4'', 1''
6. Orifice Size: 13mm, 25mm
7. Operation: Piston Pilot Operated
8. Coil Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data of 5404 Solenoid Valve:​

Model
Orifice Size
Port Size
Working Pressure
(MPa)
Medium Temperature
(℃)
Kv value
(m³/h)
Power Cunsumption
Voltage
AC
(VA)
DC
(W)
5404
13mm
1/4''
0.3 to 5
0 to +180
3.6
14
8
AC:
24V,
110V, 120V, 220V, 230V
(50/60Hz)
DC:
12V, 24V
3/8''
1/2''
25mm
3/4''
0.3 to 3.5
11
1''

Main Dimension of 5404 Solenoid Valve:

1/2'' Explosion Proof Brass Solenoid Valve High Pressure 5 MPa 24V 220V

Model
G
F
H
K
L
E
B
A
5404
1/4''
12
40
34
64
24
97
16
3/8''
1/2''
3/4''
16
40
60
92
45
124
20
1''
18

Brando Solenoid Valve Factory Production Video:
