5541 CEME Type Brass Gas Solenoid Valve For MIG TIG Welding Machine 24V 220V

  • 1
  • 2

Brand Name : BRANDO

Model Number : 5541

Certification : CE, ISO

Place of Origin : China, Ningbo

MOQ : 5 pcs

Price : Negotiation

Payment Terms : T/T, PayPal, Western Union

Supply Ability : 100000 pcs per month

Delivery Time : 4 to 7 working days

Packaging Details : Box, Carton, Pallet

Product Name : Welding Machine Solenoid Valve

Inlet Size : 1/8''

Outlet Size : Hose Connection (6.5mm OD)

Orifice Size : 2mm

Body Material : Brass

Seal Material : NBR, EPDM, FKM

Working Medium : Gas

Working Medium Temperature Range : NBR: -5 to +120 ºC, EPDM: -30 ℃ to +120℃, FKM: -30 ℃ to +150℃

Working Pressure Range : 0 to 8 bar

Voltage : 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Contact Now

5541 CEME Type Brass Gas Solenoid Valve For MIG TIG Welding Machine 24V 220V

Product Features:

1. Model No: 5541
2. Port Size: Inlet: 1/8'', Outlet: Hose Connection (6.5mm OD)
3. Orifice Size: 2mm
4. Body Material: Brass
5. Seal Material: NBR, EPDM, FKM
6. Working Medium: Gas
7. Working Medium Temperature Range: NBR: -5 to +120 ºC, EPDM: -30 ℃ to +120℃, FKM: -30 ℃ to +150℃
8. Working Pressure Range: 0 to 8 bar
9. Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
10. Application: MIG, TIG Welding Machine

Dimension and Data of 5541 Solenoid Valve:

5541 CEME Type Brass Gas Solenoid Valve For MIG TIG Welding Machine 24V 220V

Port Size
1/8'', 1/4''
Orifice Size
1mm to 3mm
Body Material
Brass
Seal Material
NBR, EPDM, FKM
Working Medium
Water, Air, Gas, Oil, Steam, etc
Working Medium Temperature Range
NBR: -10 ℃ to +80 ℃
EPDM: -30 ℃ to +120 ℃
FKM: -30 ℃ to +150 ℃
Working Pressure Range
0 to 10 bar
Operation
Direct Acting
Function
2 Way Normally Closed
Voltage
DC: 12V, 24V
AC: 24V, 110V, 120V, 220V, 230V (50/60Hz)

BRANDO Solenoid Valve Production Video:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
