Direct Acting Diaphragm Brass Water Solenoid Valve 2W400-40 1.5''

Product Categories
Ningbo Brando Hardware Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Direct Acting Diaphragm Brass Water Solenoid Valve 2W400-40 1.5''

Brand Name : Brando

Model Number : 2W400-40

Certification : CE

Place of Origin : China

MOQ : 1 pc

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100000 pcs per month

Delivery Time : 7 working days

Packaging Details : inner boxes,cartons,pallets

Valve Series : 2W Series

Ref. Number : UNI-D Type UW-40

Voltage : AC110V AV220V DC24V

Action : Pilot Diaphragm Drive

Port Size : 1-1/2' Inch

Media : Water Air Gas

Fluid Viscossity : Below 20 CST

Power : Solenoid

Body Material : Brass

Diaphragm Material : NBR, FKM and EPDM

Contact Now

Direct Acting Diaphragm Brass Water Solenoid Valve 2W400-40 1.5''

The 2W400-40 solenoid valve is brass valves two-way, semi-direct lift valve that operates in a normally closed position.This means that there are two ports in which the medium flows and the valve will open to allow the medium to pass when the coil is energized. 2 / 2 Way G1-1/2 Inch Normal Close Type Operated Brass Solenoid Valve 2W400-40.High quality electric solenoid valve, for water, air or oil. It's applicable in many fields.

2W400-40

2W: 2 Positon 2 Way Solenoid Valve. Solenoid valve has 2 pipe connections, an inlet called the cavity port and an outlet called the body orifice port. When the valve is energized the plunger opens allowing media to flow through the valve in the cavity port and out the body orifice port.Turn off the power. The orifice closes and flow through the valve stops.

400: The Aperture of Flow Rate is 40 mm

40:Joint Pipe Bore is G1-1/2 Inch Female Thread

Technical Data of 2W & 2S Solenoid Valve:

2W Series
2W025-08
2W040-10
2W160-15
2W200-20
2W250-25
2W350-35
2W400-40
2W500-50
2S Series
2S025-08
2S040-10
2S160-15
2S200-20
2S250-25
2S350-35
2S400-40
2S500-50
Orifice Size
2.5
4
15
20
25
35
40
50
Port Size
1/4''
3/8''
1/2''
3/4''
1''
1-1/4''
1-1/2''
2''
Medium
Water, Air, Gas, Oil
Action
Direct Acting
Semi-Direct Diaphragm Operated
Function
2 Way, Normally Closed
Fluid Viscosity
20 CST below
Pressure
Range
0 to 1.0 Mpa
Temp. Range
-5 to +85℃

Main dimension of 2W & 2S Series Solenoid Valves:
Direct Acting Diaphragm Brass Water Solenoid Valve 2W400-40 1.5''

2S Series
2W Series
A
B
C
D
E
2S025-06
2W025-06
64.5
30
75
43
1/8''
2S025-08
2W025-08
64.5
30
75
43
1/4''
2S040-10
2W040-10
70.6
32
82.4
53
3/8''
2S160-10
2W160-10
101.5
57
117
69
3/8''
2S160-15
2W160-15
101.5
57
117
69
1/2''
2S200-20
2W200-20
107
57
123.5
73
3/4''
2S250-25
2W250-25
111.5
73.5
134.5
99
1''
2S350-35
2W350-35
142
95
172
123
1-1/4''
2S400-40
2W400-40
142
95
172
123
1-1/2''
2S500-50
2W500-50
172
123
209
168
2''

Main Part OF 2W Solenoid Valve and its Material:

Main Body: Brass

Coil: Special Copper Wire

Core: Stainless Steel

Tube: Stainless Steel

Spring: Stainless Steel

Plug: NBR, Viton, Silicon

Diaphragm: NBR, Viton, Silicon

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
