1/2'' 321H35 High Pressure Brass Solenoid Valve 40 Bar 24VDC 220VAC
Plastic Bottle Blowing Machine Application Example:
Three 2-way solenoid valves permit to control the required blowing functions to produce plastic bottles.
In a first phase, the N.O. valves (322H35) and N.C. valves (421H35) are energised. The pressure in the circuit is therefore established to a pre-determined level (2 to 15 bar). During the same time the 3/2 valve (331B31) maintains the mould closed with a 40 bar pressure.
In a second phase, the N.C. valve 321H35 is energised and the pressure increases up to 40 bar. Independently from the position of the 421H35 valve, the 321H35 valve assures by design that the 40 bar pressure is maintained and cannot go back into the "low pressure" circuit.
In a third phase, the N.O. valve 322H35 is de-energised and permits the discharge of the circuit down to 0 bar.
Technical Data of High Pressure Solenoid Valve:
| Port Size | |
| Orifice Size | |
| Function | |
| Operation | |
| Working Medium | |
| Working Pressure Range | |
| Voltages | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz) |
Main Dimension of High Pressure Solenoid Valve:
Brando Solenoid Valve Factory Production Video:
More High Pressure Solenoid Valves for you to choose:
| Brass Solenoid Valves |
 |  |  |  |
| MAX 50 bar | MAX 50 bar | MAX 50 bar | MAX 50 bar |
 |  |  |  |
| MAX 50 bar | MAX 70 bar | MAX 120 bar | MAX 200 bar |
| Stainless Steel Solenoid Valves |
 |  |  |  |
| MAX 50 bar | MAX 50 bar | MAX 50 bar | MAX 100 bar |
 |  |  |  |
| MAX 120 bar | MAX 160 bar | MAX 200 bar | MAX 300 bar |
