3/2 Way 1/8'' 1/4'' Brass Solenoid Valve Direct Acting 24V 220V VX31

  • 1
  • 2

Brand Name : Brando

Model Number : VX31, VX32, VX33

Certification : CE

Place of Origin : China

MOQ : 1 pc

Payment Terms : L/C, T/T, PayPal, Western Union, MoneyGram

Supply Ability : 100000 pcs per month

Delivery Time : 4-8 days

Packaging Details : Inner boxes, Carton, Pallet

Port Size : 1/8'', 1/4''

Orifice Size : 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm

Operation Mode : 3 Way NC, 3 Way NO, Universal

Action : Direct Acting

Body Material : Brass, Stainless Steel

Seal Material : NBR, EPDM, FKM

Voltages : 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Pressure Range : 0 To 1 MPa

Contact Now

3/2 Way 1/8'' 1/4'' Brass Solenoid Valve Direct Acting 24V 220V VX31

The multi-purpose 3/2 way direct acting solenoid valves are mainly suitable in the neutral gaseous and liquid fluid pipeline automatically control. It is suitable the medium of gas, water, oil, vacuum, steam. Can be operated with zero pressure difference & circulation direction is random.

Product Features:

1. Working Medium: Air, Water, Steam, Oil, Gas, Vaccum, etc.
2. Working Pressure Range: 0 to 1 MPa (See the parameter table below for details)
3. Medium Temperature Range: NBR (-10 to +80℃), EPDM (-30 to +120℃), FKM (-30 to +150℃)
4. Port Size: 1/8'', 1/4''
5. Orifice Size: 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm
6. Body Material: Brass, Stainless Steel
7. Seal Material: NBR, EPDM, FKM
8. Function: 3 Way Normally Closed, 3 Way Normally Open, Universal
9. Operation: Direct Acting
10. Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Main Dimension of VX Series Solenoid Valve:

3/2 Way 1/8'' 1/4'' Brass Solenoid Valve Direct Acting 24V 220V VX31


Technical Data of VX Series Solenoid Valve:

Model
Function
Orifice Size
(mm)
Port Size
(inch)
CV
Working Pressure (bar)
Medium Temperature
AC
DC
VX31
3 Way, Normally Closed
1.5
1/8'', 1/4''
0.07
13
11
NBR: -5 to +85℃,
EPDM: -5 to +150℃,
FKM: -10 to +150℃
2.0
0.14
11
9
2.5
0.21
9
7
3.0
0.25
6
4
4.0
0.35
3.5
2
VX32
3 Way, Normally Open
1.5
0.07
13
11
2.0
0.14
11
9
2.5
0.21
9
7
3.0
0.25
6
4
4.0
0.35
3.5
2
VX33
3 Way, Universal Operation
1.5
0.07
13
11
2.0
0.14
11
9
2.5
0.21
9
7
3.0
0.25
6
4
4.0
0.35
3.5
2

Working flow direction of VX Series Solenoid Valve:

3/2 Way 1/8'' 1/4'' Brass Solenoid Valve Direct Acting 24V 220V VX31

Brando Factory Production of Solenoid Valves:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
