2 Way Household Electric Iron 5523 Brass Steam Solenoid Valve

Brand Name : Brando

Model Number : 5523

Certification : CE

Place of Origin : China

MOQ : 1 pc

Price : Negotiation

Payment Terms : L/C, T/T, PayPal, Western Union, MoneyGram

Supply Ability : 100000 pcs per month

Delivery Time : 4-8 days

Packaging Details : Inner boxes, Carton, Pallet

Medium : Water, Air, Oil, Hot Water, Steam, etc

Port Size : Inlet: 1/8'' (G, NPT); Outlet: 6.2mm OD

Orifice Size : 2mm to 3mm

Seal Material : FKM

Body Material : Brass

Working Pressure Range : 0 to 10 Bar

Function : 2 Way Normally Closed

Coil Voltage : 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Contact Now

2 Way Household Electric Iron 5523 Brass Steam Solenoid Valve

Product Feature:

1. Port Size: Inlet: 1/8'' (G, NPT); Outlet: 6.2mm OD
2. Orifice Size: 2mm to 3mm
3. Body Material: Brass
4. Seal Material; FKM
5. Working Medium; Water, Air, Oil, Steam, etc
6. Working Medium Temperature Range: -30 ℃ to +150℃
7. Working Pressure Range: 0 to 10 Bar
8. Voltages: DC: 12V, 24V; AC: 24V, 110V, 120V, 220V, 230V (50/60Hz)

Dimension and Data of Steam Iron Solenoid Valve:

2 Way Household Electric Iron 5523 Brass Steam Solenoid Valve

Model
5523
Port Size
Inlet: 1/8'' (G, NPT)
Outlet: 6.2mm OD
Orifice Size
2mm to 3mm
Body Material
Brass
Seal Material
FKM
Working Medium
Water, Air, Oil, Steam, etc
Working Medium Temperature Range
-30 ℃ to +150℃
Working Pressure Range
0 to 10 Bar
Voltages
DC: 12V, 24V
AC: 24V, 110V, 120V, 220V, 230V (50/60Hz)


Brando Factory Production of Solenoid Valves:

More Steam Iron Solenoid Valves for you to choose:

2 Way Household Electric Iron 5523 Brass Steam Solenoid Valve 2 Way Household Electric Iron 5523 Brass Steam Solenoid Valve 2 Way Household Electric Iron 5523 Brass Steam Solenoid Valve 2 Way Household Electric Iron 5523 Brass Steam Solenoid Valve
2 Way Household Electric Iron 5523 Brass Steam Solenoid Valve 2 Way Household Electric Iron 5523 Brass Steam Solenoid Valve 2 Way Household Electric Iron 5523 Brass Steam Solenoid Valve 2 Way Household Electric Iron 5523 Brass Steam Solenoid Valve

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
