Goyen Type CA76T 3'' Threaded Dust Collector Valve For Baghouse

Name: Goyen Type CA76T 3 Threaded Dust Collector Valve For Baghouse
Brand: Brando
Price: 1 USD

China Goyen Type CA76T 3'' Threaded Dust Collector Valve For Baghouse factory

Brand Name : Brando

Model Number : CA76T

Certification : CE

Place of Origin : China Ningbo

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T, PayPal, Western Union, L/C

Supply Ability : 100000 pcs per month

Delivery Time : 4-7 days

Packaging Details : Inner Boxes, Carton, Pallet

Port Size : 3''

Valve Series : T

Valve Structure : Right Angle, Threaded Port

Diaphragm Material : NBR, FKM

Working Pressure Range : 0.35 To 0.85 MPa

Coil Voltage : 24VDC, 110VAC, 220VAC

Contact Now

Goyen Type CA76T 3'' Threaded Dust Collector Valve For Baghouse

BRANDO has developed pulse valve and pulse jet valve for reverse pulse jet bag filters, offering precisely engineered valve of market need. Pulse Valve has just one moving part , the Spare diaphragm . The unique springless construction provides fast opening and closing of the valve. The high speed operation besides saving of compressed air,helps to provide shock air wave for dislodging of dust from filter bags. High flow,long life and fast diaphragm action produce reliable and economical operation.

Technical Data of T Series Pulse Jet Valves:

Model No	CA15T	CA20T	CA25T	CA35T	CA45T	CA50T	CA62T	CA76T
Office Size (mm)	15	20	25	35	45	50	62	76
Port Size (Inch)	1/2''	3/4''	1''	1 1/2''	1 1/2''	2''	2 1/2''	3''
Diaphragm Number	1				2
Working pressure	0.35 to 0.85 MPa (5 to 125 PSI)
Voltage	24VDC, 24VAC, 110VAC, 220VAC
Diaphragm Material	NBR, FKM, EPDM
Body Material	Aluminum Alloy
Valve Structure	Right Angle (Outlet is at 90° to Inlet), Threaded Port

Ordering Code of T Series Pulse Jet Valve:

Goyen Type CA76T 3'' Threaded Dust Collector Valve For Baghouse

Main Dimension of CA76T Pulse Jet Valve:

Goyen Type CA76T 3'' Threaded Dust Collector Valve For Baghouse

Video of CA76T Pulse Jet Valve:

More Goyen Type Pulse Valves for you to choose:


T Series	DD Series	FS Series	MM Series

RCA Series	Solenoid Coil	Solenoid Armature	Diaphragm

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
